The catalyst support is made from cordierite and is most often applied in catalyst converter of diesel emission purification system. After the catalytic conversion and purification, exhaust gases can be compliant with European IV and European V Standard. In the selective catalytic reduction process, NOXis reduced into N2 and water by ammonia or urea solution. With application of porous catalyst carrier and good-quality catalyst, a high conversion rate and high durability are realized.
Main Characteristics of SCR Catalyst Support
1. Large specific surface area
2. Small backpressure
3. High compressive strength
4. Small coefficient of thermal expansion
5. Good water absorption performance
6. High uniformity
7. Resistance to thermal shock
7. Applicable to various catalysts
Specifications of SCR Catalyst Support
Common Size: 100 holes / inch2-400 holes / inch2. Professional customization service is available.
| NO. | Section size (mm) | Cross-sectional area (mm2) | Sides of cross section | Height (mm) |
| 1 | 144 | 16282 | 3 | Customized |
| 2 | 150 | 17671 | 3 | |
| 3 | 165 | 21382 | 3 | |
| 4 | 170 | 22698 | 3 | |
| 5 | 175 | 24052 | 3 | |
| 6 | 190 | 28352 | 3 | |
| 7 | 210 | 34636 | 3 | |
| 8 | 228 | 40828 | 3 | |
| 9 | 240 | 45238 | 3 | |
| 10 | 267 | 55990 | 3 | |
| 11 | 286 | 64242 | 3 | |
| 12 | 305 | 73061 | 3 | |
| 13 | 330 | 85529 | 3 |
