The methanol synthetic catalyst offered by Hualian is made using aluminum oxide, Ni active component and addition agent. The catalyst for methanol synthesis provides excellent compressive strength, high low-temperature activity and good thermal stability. Compared to commonly-used catalysts, this aluminum oxide catalyst has a service life up to five years, 30% longer than peer products. The methanol synthesis catalyst is in a pre-reduction state and can also be processed in an oxidation state.
Application
The chemical catalyst is mainly used in methanol synthesis of hydrogen and nitrogen or oxycarbide hydrogenation to methanol.
Specifications of Methanol Synthesis Catalyst HL-103
| Items |
Parameters |
| Appearance |
Black ball |
| Size, mm |
3-5 |
| Crushing strength, N/particle |
≥ 80 |
| Bulk density, kg/L |
0.75–0.85 |
| Ni content, % |
≥ 18 |
| Catalyst attrition, wt% |
Max. 3 |
| Catalytic activity |
0.05NL CH4/h/g catalyst |
Working Environment
| Items |
Pressure, Mpa |
Temperature, ℃ |
Space velocity, hr-1 |
| 3.0 |
250-300 |
7000-10000 |
| Raw materials |
CO2 1.2%, the rest: hydrogen: nitrogen, 3:1 |
| Products |
CO2+CO≤ 10ppm. |
HL-103H
| Items |
Parameters |
| Appearance |
Black column |
| Size, mm |
∮(5–6)×(5–20) |
| Crushing strength, N/cm |
≥ 150 |
| Bulk density, kg/L |
0.80 –0.90 |
| Ni content, % |
≥ 18 |
| Catalyst attrition, wt % |
Max. 5 |
| Catalytic activity |
0.05NL CH4/h/g catalyst |
Working Environment
| Items |
Pressure, Mpa |
Temperature, ℃ |
Space velocity, hr-1 |
| 3.0 |
250-300 |
7000-10000 |
| Raw materials |
CO2 1.2%, the rest: hydrogen: nitrogen, 3:1 |
| Products |
CO2+CO≤ 10ppm. |
HL-103TH
| Items |
Parameters |
| Appearance |
Tablet |
| Size, mm |
5×5 |
| Crushing strength, N/particle |
≥80 |
| Bulk density, kg/L |
0.85-0.95 |
| Ni content, % |
≥ 34 min |
| Catalyst attrition, wt% |
Max. 3 |
| Catalytic activity |
0.05NL CH4/h/g catalyst |
Working Environment
| Items |
Pressure, Mpa |
Temperature, ℃ |
Space velocity, hr-1 |
| 3.0 |
250-430 |
7000-12000 |
| Raw materials |
CO 0.3%, the rest: hydrogen: nitrogen, 3:1 |
| Products |
Total content ≤ 1ppm. |
